Get the Effective Height and Width of the Browser When the Software Keyboard Appears in iOS Safari and Adjust the Layout
2023-07-16 20:02 (1 years ago)
ytyng
When implementing a page layout with a fixed footer, there might be cases where the layout breaks when the software keyboard is displayed on iOS.
To resolve this, I made the maximum height of the layout a CSS variable and updated it continuously in the case of iOS.
:root {
--visual-viewport-height: 100%;
}
body {
height: var(--visual-viewport-height);
}const w = window as any;
const refreshSize = () => {
w.document.documentElement.style.setProperty('--visual-viewport-height', `${w.visualViewport.height}px`)
w.scrollTo(0, 0)
}
w.mobileUIRefreshInterval = setInterval(refreshSize, 300)
refreshSize()
// To clear the condition
...
clearInterval(w.mobileUIRefreshInterval)Additional Information
There's a -webkit-fill-available option for calculating 100vh correctly in iOS Safari
Although it wasn't suitable for this use case, it might be useful for other purposes, so I'll note it here.
body {
height: 100vh;
}
@supports (-webkit-touch-callout: none) {
body {
/* The hack for Safari */
height: -webkit-fill-available;
}
}Reference: Adjusting 100vh appropriately to display elements full-height on iOS
When the software keyboard is displayed, scrolling is forcibly enabled
Even if overflow: fixed is set on body, iOS forcibly enables scrolling when the software keyboard is displayed.
In this scenario, for a web app layout with a fixed footer, the user experience is not ideal.
There are several countermeasures, but I found that periodically executing window.scrollTo(0, 0) via setInterval is effective. Although there is a slight flickering issue when the window scrolls, it's practically stable and sufficient.
